Fiber optic connector, or optical fiber connector, is a component to terminate the end of fiber optical cable, and enables quicker connection and disconnection than fiber splicing. It mechanically couples and aligns the fiber cores to make light pass successfully. Therefore, fiber optic connector has an important impact on the fiber optic transmission reliability and the performance of the system. Quality optical connectors lose very little light due to reflection or misalignment of the fibers.
Model Number:SC
Color:Violet
Material:plastic,Zinc alloy
model:SC/OM4
Application:Optical fiber jumper manufacturing, FTTH
Cable Diameter:1.2mm
Single-Mode Fiber:MultiMode
Material | plastic, zinc alloy |
Cable Diameter | 2.0mm/3.0mm |
Fiber Count | Simplex |
Fiber Mode | MultiMode |
Polish Type | PC |
Insertion Loss | @850/1300nm≤0.2dB |
Return Loss | ≥30dB (PC) |
Durability | >1000times |
Operating Temp | -40~+85°C |
More Products:
Zhejiang Yingfeng Optical Communication was established in 1982, Specializing in the production of optical fiber connector, optical fiber Adapter,Fiber Optic patchcord, pigtail,PLC splitters,etc. With high quality and good reputation, it is widely used in all kinds of FTTH, FTTB, FTTX communication fields, and has been exported to the world for many years.
FAQS:
1.Are you a factory or a trader?
We are the factory.Welcome to visit our factory at any time.
2. What payment methods are supported on Zhejiang Yingfeng?
We accept Paypal, Credit Card, Bank Transfer, and Net Terms. For more information, please talk with our sales team.
3. which transport method is supported?
Usually by air, sea, or express.
4. How can I check the lead time for the product?
If the product is sufficient in the warehouse, we can ship within 3 days on business days.
